Diagnostic Connector Pin-Outs from Bosch ESI 2013.2

Diagnostic Connector Pin-Outs from Bosch ESI 2013.2

Multi-brand automotive diagnostic connector pin-out and connection reference based on Bosch ESI 2013.2 data. Designed as a workshop reference for identifying diagnostic connectors, pins and related vehicle connection information.

Main Functions

• Diagnostic connector pin-out reference
• Connector and pin identification
• Diagnostic connector location reference where included
• Power, ground and diagnostic communication-line identification where documented
• Workshop troubleshooting and diagnostic-interface connection reference
• Vehicle/system-specific connector information where available

Connector & Protocol Reference

Bosch ESI documentation from this product family includes automotive diagnostic connection information associated with common connector types such as 16-pin J1962/OBD-II and, in applicable commercial-vehicle contexts, 6-pin and 9-pin Deutsch connections and multipin/universal adapter connections. Exact contents of this 2013.2 package should be verified before purchase.

Support / Coverage

Intended as a multi-brand vehicle diagnostic connection reference. Coverage varies by vehicle manufacturer, model, model year, ECU/system and connector type. Bosch ESI ecosystems have historically covered passenger cars and commercial-vehicle applications from multiple manufacturers, but inclusion of any specific brand or model in this 2013.2 pin-out package is not guaranteed.

Compatibility Notice

Important: This is legacy 2013.2 reference data. Always verify pin assignments against the exact vehicle, ECU/system and current manufacturer service information before making electrical connections. Incorrect pin connections can damage vehicle electronics or diagnostic equipment.

For professional automotive diagnostic and repair reference use.
