Nissan UDS Tool – RH850 Gen 3 ECU DTC, Grill Shutter, EGR & EVAP Software
Nissan UDS Tool is a professional ECU firmware processing and calibration solution developed for modern Nissan Hitachi RH850 Gen 3 ECUs, with coverage stated for supported Nissan applications from 2019–2026.
Designed for automotive ECU programmers, calibration specialists and professional workshops, the software processes supported 4 MB ECU BIN files and provides automatic DTC detection together with specialized calibration functions.
Main Features
- Nissan Hitachi RH850 Gen 3 support
- Designed for supported Nissan 2019–2026 applications
- 4 MB BIN file processing
- RH850 firmware analysis
- Nearly 500 mapped DTC entries
- Individual DTC selection and management
- Active Grill Shutter calibration function
- EGR calibration function
- EVAP calibration function
- Automated file processing
- 16-bit binary processing
- Fast BIN file scanning
- No manual HEX editing required for supported functions
- Professional ECU calibration workflow
Supported ECU Architecture
Hitachi RH850 Gen 3
The software is specifically designed around supported modern Nissan Hitachi RH850 Gen 3 ECU architecture.
Supported Microcontrollers
Renesas R7F701202
- RH850 architecture
- Supported 4 MB BIN file applications
- Automatic firmware processing where compatible
Renesas R7F701216
- RH850 architecture
- Supported 4 MB BIN file applications
- Automatic firmware processing where compatible
Supported BIN File Size
4 MB / 4096 KB BIN files
The original ECU firmware should be correctly read using a compatible professional ECU programming tool before processing.
DTC Management
Nissan UDS Tool incorporates a built-in database containing nearly 500 mapped DTC entries for supported firmware.
The system is designed to automatically scan compatible ECU files and locate supported DTC positions without requiring technicians to manually search through HEX data.
Functions include:
- Automatic DTC detection
- Individual DTC selection
- DTC file management
- Fast firmware scanning
- Automated binary modification
- Multiple supported DTC processing
- Reduced need for manual HEX editing
Actual available DTC coverage depends on the ECU software version and original firmware.
Active Grill Shutter Calibration
A dedicated Active Grill Shutter file-processing function is available for compatible ECU firmware.
This can assist professional workshops when diagnosing, repairing or configuring supported Active Grill Shutter systems.
EGR Calibration
Dedicated EGR-related calibration processing is available for compatible firmware.
Function availability depends on the exact ECU hardware and software version.
Emission-related modifications must only be performed where permitted by applicable regulations.
EVAP Calibration
Nissan UDS Tool also provides dedicated EVAP-related calibration processing for supported ECU files.
This function is intended for legitimate diagnostic, repair, development and other legally permitted professional applications.
Fast Automatic Processing
The software is designed to automate supported binary-file operations.
Instead of manually locating individual HEX addresses, the software analyzes compatible firmware and applies the supported file-processing operation automatically.
This can significantly reduce processing time and the risk of manual editing errors.
Vehicle Coverage
Primary supported manufacturer:
Nissan
The developer states coverage for compatible Nissan applications from:
2019–2026
Vehicle year alone does not guarantee compatibility. The ECU architecture, MCU and firmware version must also match the software’s supported database.
Support List
Vehicle Brand
- Nissan
ECU Manufacturer / Architecture
- Hitachi
- RH850 Gen 3
Supported MCU
- R7F701202
- R7F701216
Supported File
- 4 MB BIN
Supported Software Functions
- ECU BIN file analysis
- DTC detection
- DTC management
- Nearly 500 mapped DTC entries
- Active Grill Shutter calibration
- EGR calibration
- EVAP calibration
- Automatic binary processing
- Modified BIN file generation
ECU Programmer Compatibility
A compatible ECU programmer is required to read and write the ECU.
Depending on the exact ECU and programmer, communication may be performed through:
- OBD
- Bench
- Boot
Always verify the programmer protocol for the specific ECU before attempting a read or write operation.
Recommended Professional Workflow
Identify ECU → Read Original ECU → Save Original Backup → Load 4 MB BIN File → Scan Firmware → Select Supported Function → Process File → Verify Output → Write ECU
Always keep the untouched original file.
Compatibility Check Before Purchase
For accurate compatibility verification, please provide:
- Nissan model
- Model year
- Engine type
- Engine displacement
- ECU manufacturer
- ECU part number
- Hardware number
- Software number
- MCU number
- Original BIN file
- BIN file size
- ECU programming tool
- Reading method
Suitable For
Nissan UDS Tool is suitable for:
- ECU programming workshops
- Nissan diagnostic specialists
- ECU repair technicians
- Automotive electronics workshops
- ECU calibration professionals
- Automotive software specialists
- Professional tuning workshops
- ECU file-processing services
Important Notice
ECU compatibility depends on the exact hardware number, software number, MCU and firmware version.
Always retain the original ECU backup before processing or programming.
Use a regulated power supply/battery support unit during ECU programming.
Do not interrupt ECU programming while a write operation is in progress.
EGR, EVAP and related emissions-system calibration functions should only be used for lawful repair, diagnostics, development, testing, motorsport/off-road applications where legally permitted.
JDTCL Technical Support
Jabedul Dewan Trading LLC (JDTCL) provides professional technical support for compatible Nissan ECU programming applications, including:
- Software installation assistance
- Software configuration
- ECU identification assistance
- RH850 MCU identification
- BIN file compatibility checking
- ECU programmer selection guidance
- OBD / Bench / Boot setup guidance
- Original ECU backup guidance
- ECU read/write workflow support
- Remote technical assistance
- After-sales support
Jabedul Dewan Trading LLC
Global Trusted Automotive Tech Provider
UAE | Bangladesh | Oman | Qatar | Bahrain | Worldwide
WhatsApp / Technical Support: +971 50 997 0171
Website: auto-scan-tool.com
Compatibility Notice
Please send your ECU label, HW/SW identification or original 4 MB BIN file before purchase if you need confirmation for a specific Nissan ECU.
