How Audi-VW Airbag Reset Toot works:
All Audi-VW airbag systems after car crash and airbag deployment are locked. Even after small accident Airbag sensor will write in internal memory special error message “crash data stored” and after you need to exchange very expensive sensor to new one.
With our Audi-VW Airbag Reset Tool you can reset and repair airbag computer in your office in 1 minute. No need to remove airbag sensor from the car. Fully automatic sensor type recognizing.
Audi-VW Airbag Reset Tool works without additional computer and thought car OBD II connector can erase airbag sensor “crash data” or only fault memory.
Workable Model:
Works with all VW/Audi airbag sensors to year 2003,
AD A4, A6, A8 1994-1997,
Airbag V BOSCH:
8A0 959 655 C (Bosh 0 285 001 038)
8A0 959 655 K (Bosh 0 285 001 155)
8A0 959 655 K (Bosh 0 285 001 151)
Crash data erase & Fault erase
AD A3, A4, A6, A8 <1999,
Airbag 7 BOSH:
4B0 959 655 C
4B0 959 655 J
4D0 959 655 C
4D0 959 655 H
8D0 959 655 C
8D0 959 655 L
8L0 959 655 F
all B-o-s–c–h Airbag 7
Crash data erase & Fault erase
Audi A2, A3, A4, A6, A8 – 1999,
Airbag 8 BOSH:
Crash data erase & Fault erase (can erase “Controller Malfunction”);
VW – Go—lf III, Pasat B4, Sharan:
1J0 909 603 SIEMENS
Crash data erase & Fault erase
VW – Golf IV, Pasat B5,
Siemens:
1J0 909 609
1J0 909 607
Crash data erase & Fault erase
VW – Golf IV, Pasat B5,
Bosch:
3B0 959 655 B
8L0 959 655 A
Crash data erase & Fault erase
VW – Golf IV, Pasat B5, Sharan:
Siemens:
6Q0 909 605 A
6Q0 909 605 B
Crash data erase & Fault erase
VW – Golf IV, Pasat B5, Sharan,
Siemens:
1C0 909 605 C
1C0 909 605 F
1C0 909 605 H
6Q0 909 605 C
Crash data erase & Fault erase
V–W – Pas—sat B6 2001-2004,
new SIE–ME–NS V—W5, V–W51, V–W61
Crash data erase & Fault erase
Skoda, Seat all SIEMENS
Crash data erase & Fault erase
Now support new Audi airbag sensors 1999-2002 DTC65535 (Controller Malfunction) erase by OBDII
connector. Works with all sensor types:
8L0 959 655 G (B0—sch 0 285 001 352) and others with HC12 processor
4D0 959 655 J (B0—sch 0 285 001 266)
8D0 959 655 J (B0–sch 0 285 001 276)
8D0 959 655 F (B0—-sch 0 285 001 270)
8D0 959 655 M and others with National CR16 (44 PLCC)
Airbag Reset Operating Instructions:
Very simple user instruction:
connect this tool to Audi/VW car OBD II connector. Right red button is for airbag “crash data” erase. Push this button once and wait: yellow light start to flash and after 15 second green light inform you that “crash data” is erased. Red light set ON if erasing is not successful. Left yellow button is for erase airbag “fault memory” or “errors”. If airbag warning lamp go OFF and immediately ON, evaluate airbag “error memory” using any VW—Audi diagnostic equipment and repair.
External Testing Certification: ce
Hardware Version: Airbag Reseter
Special Features: via OBD interface
Software Version: Airbag Reseter Tool
Model Name: vag rester tool
Item Type: Air Bag Scan Tools & Simulators
Electronic: No
Material Type: ABS
Model Name: Airbag Reseter
Keyword: Airbag SRS Crasher Data Reseter OBD2
Feature: Auto Diagnostic Tool
Material Type: Plastic ABS Airbag SRS
Item Weight: 0.3kg ABS SRS airbag tool
Function: Auto Airbag Reseter
Performance: Good Airbag Reseter Tool
Special: erase airbag sensor
Package: carton package
Item Type: Air Bag Scan Tools & Simulators
