Xhorse VVDI Multi-Prog – ECU, TCU, MCU & EEPROM Programmer Details
The Xhorse VVDI Multi-Prog is the newer-generation professional programmer developed as the successor to VVDI PROG. It combines ECU/ECM, TCU/gearbox, MCU, EEPROM, FLASH, dashboard and selected immobilizer/module programming functions in one platform. It supports Bench and Boot programming for many ECU/TCU families and receives online database/software updates.
Main Functions
– ECU/ECM read, write and supported cloning
– TCU/gearbox read, write and supported cloning
– EEPROM and FLASH read/write
– MCU programming
– Bench Mode programming
– Boot Mode programming
– ECU backup and recovery workflows
– Automatic checksum correction on supported ECU families
– Data comparison
– MEDC17/EDC17 data calculation support
– Bosch BMW ISN read/write on supported applications
– Dashboard/instrument-cluster memory programming
– Selected immobilizer/module data read/write for authorized repair and replacement
– Online software/database updates
– Third-party plug-in architecture
– Wiring diagrams and connection information for supported modules
Compared with the older VVDI PROG, Multi-Prog adds ECU/TCU cloning capabilities, checksum/data-processing features, BMW bench ISN functions and a more extensible software architecture. blog.xhorsevvdi.com
ECU / ECM Support List
Volkswagen / Audi / VAG
Supported families include:
Continental / Siemens
– SIMOS PCR2.1
– SIMOS 8.3x
– SIMOS 8.4x
– SIMOS 8.5x
– SIMOS 8.6x
– Later database updates also added SIMOS 18.1, 18.3, 18.6 and 18.7 applications. blog.xhorsevvdi.com
Bosch MED / EDC
– MED17.1.6
– MED17.1.21
– MED17.1.61
– MED17.5 / 17.5.1 / 17.5.2
– MED17.5.5 TC1766 / TC1767
– MED17.5.20 / 17.5.21 / 17.5.25
– EDC17C46
– EDC17C64
– EDC17C74
– EDC17CP24
– EDC17CP44
– EDC17CP54
– EDC17U01
– EDC17U05
Bosch MG1 / MD1
– MG1CA811
– MG1CS001
– MG1CS002
– MG1CS008
– MG1CS011
– MG1CS111
– MD1CP004
– MD1CP014
– MD1CS004
These include TC298TP and SPC5777 variants depending on controller. blog.xhorsevvdi.com
BMW / MINI
Multi-Prog support includes selected:
Continental
– MSD80
– MSV80
– MSD81
– MSD85
– MSD87
– MSV90
Bosch
– EDC17CP09
– EDC17C50
– EDC17CP45
– EDC17C06
– EDC17C56
– ME17.2.1
– MEVD17.2.3
– MEVD17.2
– MEVD17.2.4 N20
– MEVD17.2.6
– MEVD17.2.9
– MEVD17.2.G N55
– MEVD17.2.H
– MEVD17.2.P
– MEVD17.2.K
– MEV17.2 TC1766/TC1767/TC1796
The October 2026 update information also reports support for selected locked BMW B48/B58/N55/S58 DMEs manufactured from June 2020 onward, including MG1/MD1 controllers. Compatibility should be confirmed against the exact ECU number before programming. blog.xhorsevvdi.com
Mercedes-Benz
Selected support includes:
– Continental SIM271 DE
– Continental SIM271 KE
– Bosch ME17.7
– MED17.7.1
– MED17.7.2
– MED17.7.3
– MED17.7.3.1
– ME17.7.8
– EDC17CP10
– EDC17CP46
– EDC17CP57
– EDC17CP60
– Delphi CRD2.x MPC556x blog.xhorsevvdi.com
Nissan
Examples include:
– Denso 23740-3Nxxx Gen1 SH72531
– Bosch EDC17C84 blog.xhorsevvdi.com
Hyundai / Kia
Examples include:
– Bosch ME17.9.11
– ME17.9.11.1
– MEG17.9.12
– EDC17C53
– Delphi MT86
– DCM6.2AP applications blog.xhorsevvdi.com
Ford
Examples include:
– Bosch EDC17C70
– EDC17CP65
– ME17.0.3
– ME17.8.5 blog.xhorsevvdi.com
Volvo
Selected Bosch:
– EDC17CP22
– EDC17CP48
– EDC17CP48 Ver.2 blog.xhorsevvdi.com
GM / Chevrolet / Opel
Selected Delphi/Delco families include:
– MT80
– MT80.1
– E37
– E38
– E39 / E39A
– E67
– E78
– E80
– E82
– E83 / E83A / E83B
– E84
– E87
– E92
– E98 blog.xhorsevvdi.com
Other ECU Families
Published Multi-Prog support also includes selected:
– Bosch MG1CA007
– ME17.8.8
– ME17.8.31
– ME17.9.52
– EDC17C55
– EDC17C10
– EDC17CP42
– EDC17CP14
– EDC17C81
– MEVD17.8.4
– MED17.8.10
– MD1CS018
– MG1CS026
– MG1CS032
– MG1CS163
– MD1CS012
– MD1CS089
– MD1CS069
– MD1CS005
– MG1CS015/016/017/018/019/088
– Continental SID208
– SID209
– SID211
– SID807EVO
– SID310
– Denso KH / ZY / SH70xx families
– Marelli 8DF
– Marelli MM10JA blog.xhorsevvdi.com
TCU / Gearbox Support
Multi-Prog can read/write and, on supported applications, clone transmission controllers.
VAG DSG / S-Tronic
– DL382
– VL381
– DL501 Gen1
– DL501 Gen2
– DQ200 Dxx
– DQ200 G2
– DQ200 G2 PQ
– DQ200 MQB
– DQ250 MQB
– DQ250 Exx/Fxx
BMW
– Getrag DKG436 Gen1
– Getrag DKG436 Gen2
– Later database additions include selected 7DCT300 Boot applications.
Mercedes-Benz
– VGS-FDCT
– VGS2-FCVT
– VGS2-FDCT
Ford
– Getrag MPS6
– DPS6
– DC4
Other
– ZF 9HP
Ford DPS6/DC4 are also listed for Boot-mode read/write. blog.xhorsevvdi.com
MCU / EEPROM / FLASH Support
The platform is designed for much more than ECU/TCU work. The listing describes support for NEC, MPC and Infineon chips as well as EEPROM/FLASH and dashboard applications. Current database updates have continued adding and optimizing Renesas, Microchip, STM32, SPC and other MCU families.
Typical supported categories include EEPROM, FLASH, MCU, dashboard/cluster, ECU/TCU and other automotive electronic modules. Exact chip support should be checked inside the current Multi-Prog software because its database continues to expand. blog.xhorsevvdi.com
Vehicle Brand Coverage
The current product listing specifically mentions extended coverage for BMW, Mercedes-Benz, Volkswagen, Audi, Porsche, Land Rover, Volvo, Nissan, Hyundai and Ford, with additional applications available through the expanding database.
MQB48 / NEC35XX
The listing states that MQB48 NEC35XX support can be available without an additional activation when Multi-Prog is linked with VVDI2 Full or Key Tool Plus, subject to Xhorse’s applicable account/licensing requirements.
Package Contents
The current package lists:
– Xhorse VVDI Multi-Prog main programmer
– OBD cable
– USB cable
– VH24 adapter
– VH20 adapter
– MCU cables
– ECU cables
– Power cable
– Power supply
– 43 pins
– Packaging box
Software & Updates
The listing states free software and firmware updates, while the Multi-Prog software/database can be updated online as Xhorse adds coverage. Because support evolves frequently, checking the exact ECU/TCU part number in the latest database before connecting is recommended
Vehicle Brand Coverage
The current product listing specifically mentions extended coverage for BMW, Mercedes-Benz, Volkswagen, Audi, Porsche, Land Rover, Volvo, Nissan, Hyundai and Ford, with additional applications available through the expanding database.
MQB48 / NEC35XX
The listing states that MQB48 NEC35XX support can be available without an additional activation when Multi-Prog is linked with VVDI2 Full or Key Tool Plus, subject to Xhorse’s applicable account/licensing requirements.
Package Contents
The current package lists:
– Xhorse VVDI Multi-Prog main programmer
– OBD cable
– USB cable
– VH24 adapter
– VH20 adapter
– MCU cables
– ECU cables
– Power cable
– Power supply
– 43 pins
– Packaging box
Software & Updates
The listing states free software and firmware updates, while the Multi-Prog software/database can be updated online as Xhorse adds coverage. Because support evolves frequently, checking the exact ECU/TCU part number in the latest database before connecting is recommended
