OBDSTAR ECU MASTER – Professional ECU TCU Programmer OBD Bench Boot JTAG BDM

OBDSTAR ECU MASTER – Professional PC-Based ECU/TCU Programmer Details

OBDSTAR ECU MASTER is a professional PC-based all-in-one ECU and TCU programming platform for supported passenger cars, EVs, motorcycles, heavy-duty vehicles and selected SRS/other control modules. Depending on the selected configuration and controller, programming modes include OBD, BENCH, BOOT, JTAG and BDM.

Main Functions

• ECM / ECU read and write
• TCM read, write and supported cloning workflows
• BCM / Body / Chassis module programming
• Supported EV BMS / VCU programming
• ECU/TCU backup, recovery and replacement workflows
• Internal/external EEPROM and Flash read/write
• MAP data read/write on supported controllers
• Checksum processing where supported
• VIN read/write where supported
• Supported virgin/reset and module replacement workflows
• OBD, BENCH, BOOT, JTAG and BDM programming
• CAN-FD applications
• Guided wiring and connection information

Configuration A – Passenger Cars & EV

Designed for supported passenger-car and EV ECM, TCM, BCM, body/chassis, BMS and VCU applications. Coverage includes selected Mercedes-Benz, BMW, Jaguar/Land Rover, Hyundai/Kia, Ford, Volkswagen Group and other vehicle/controller families. Examples include selected Mercedes FBS3/FBS4 TCM, AISIN TCM, BMW 8HP GEN3, JLR 8HP/9HP, Hyundai/Kia CAN-FD KEFICO, Ford MG1/MD1, VAG SIMOS/ME17/EDC17 and selected Marelli applications.

Configuration A License – AED 4,603.16

Configuration B – Motorcycle

Dedicated to supported motorcycle ECM programming, read/write, backup, cloning and replacement workflows. Coverage includes selected Harley-Davidson, Honda, CFMOTO, Kawasaki, BMW, Kymco, Loncin, Moto Morini, Segway, Voge, Zontes and other applications depending on ECU family and software version.

Configuration B License – AED 2,113.25

Configuration C – Heavy Duty / Truck / Tractor / OHW

For supported commercial and off-highway ECM, TCM and other module applications. Coverage includes selected Mercedes-Benz, Volvo, Scania, MAN, Iveco, Isuzu, Mitsubishi Fuso, FAW, Ford, John Deere, CNH Industrial, Kubota and Yanmar applications. Controller families include selected Bosch, Denso, Continental, Delphi, Siemens, Cummins, WABCO and ZF systems.

Configuration C License – AED 5,938.61

Configuration D – SRS / Battery / SAS

Provides supported SRS/Airbag, battery and steering-angle-sensor service applications. SRS functions are intended for legitimate post-repair restoration after the underlying restraint-system fault and damaged components have been repaired or replaced.

Configuration D License – AED 1,536.02

Software Update License

The platform includes a software update period according to the applicable OBDSTAR package/activation terms. Renewal is available for continued access to new coverage and updates.

1-Year Multiple-Configuration Update License – AED 2,201.30

Technical Requirements

PC-based operation. OBDSTAR specifies Windows 10 or later, 14V/24V operation and communication support including CAN, J1708, ISO 15765, SAE J1939, ISO 9141, KWP2000 and SAE J1850 depending on the application.

Compatibility Notice

Functions and vehicle coverage vary by configuration, vehicle, ECU/TCU part number, processor, model year and software version. Always verify the exact module in the latest OBDSTAR coverage database before programming. Security-sensitive functions should only be used on vehicles owned by or authorized for the technician.
