ODX and CBF Files 03.2017 is a Mercedes-Benz ECU diagnostic-data collection intended for use with compatible Vediamo engineering diagnostic environments.

These database files provide the diagnostic descriptions required for supported control units, allowing compatible engineering software to understand ECU communication parameters, diagnostic services, actual values, routines and available coding parameters. Nexus Auto

Main Features

– Mercedes-Benz ECU diagnostic database

– ODX diagnostic data

– CBF ECU description files

– 03.2017-era database collection

– Intended for compatible Vediamo engineering workflows

– ECU identification and communication definitions

– Diagnostic Trouble Code (DTC) definitions where supported

– Actual/live-value definitions

– Actuator/test definitions where supported

– ECU routines and service definitions

– Variant-coding parameter definitions where supported

– ECU communication parameters and diagnostic-session information

A CBF file essentially describes how compatible engineering diagnostic software communicates with and interprets a particular ECU. ODX is an ISO 22901 standardized diagnostic-data format used to describe ECU diagnostic capabilities in a machine-readable structure. Nexus Auto

ECU / System Support

Depending on the files contained in the 03.2017 database, Mercedes diagnostic datasets from this generation can cover many electronic-control systems, including:

Engine & Powertrain

– Petrol engine ECU

– Diesel engine ECU

– Transmission / gearbox control

– Transfer-case control

– Selected drivetrain modules

Brake & Chassis

– ABS

– ESP

– Electronic brake systems

– Suspension / AIRMATIC-related modules

– Steering-related control units

Body Electronics

– Front and rear SAM modules

– Central Gateway

– Door control modules

– Seat control modules

– Electronic ignition/EIS-EZS systems

– Lighting and headlamp-control modules

Safety & Comfort

– SRS / airbag control

– HVAC / climate control

– Seat-belt related modules

– Parking-related systems

– Selected convenience modules

Infotainment & Instrumentation

– Instrument cluster

– COMAND/head-unit related modules

– Display systems

– Telematics-related control units

Published CBF databases contain examples such as ME, CR, ESP, EZS, SAM, HVAC, CGW, VGS, COMAND and SRS-related control-unit descriptors, although the presence of a family in another CBF database does not prove that every corresponding file is present in this exact March 2017 package. obdtotal.com

Mercedes-Benz Vehicle Support

The database is intended for Mercedes-Benz / Daimler diagnostic applications. Depending on ECU generation and the exact files supplied, coverage can span multiple Mercedes passenger-car platforms and control-unit generations.

Examples of chassis/platform families associated with CBF-era Mercedes diagnostic data include:

W/S/C 204, W/S 212, W221, W166, W164, W169, W171/R171, W172/R172, W203, W209, W211, W220, W230/R230, W231/R231, W240, W245, W463, C197/R197 and additional Mercedes platforms.

Newer Mercedes generations increasingly moved toward ODX/SMR-D-based diagnostic descriptions, while CBF is particularly associated with older CAESAR/DIOGENES diagnostic environments. GitHub

CBF vs ODX vs CFF

File Main purpose

CBF ECU diagnostic description, services, parameters, routines and coding definitions

ODX Standardized diagnostic-data description format

CFF ECU software/firmware used for applicable flashing operations

Therefore, having a compatible CBF or ODX file does not automatically mean the corresponding ECU firmware/flash file is included. Nexus Auto

Important Compatibility Notice

03.2017 refers to legacy diagnostic data. Exact support depends on the vehicle chassis, ECU/module, hardware/software generation, diagnostic interface, Vediamo version and the individual CBF/ODX files actually included in the package.

A control unit or Mercedes chassis appearing in a general support reference does not guarantee that every variant or function is available in this specific 03.2017 collection.

Use engineering diagnostic functions only on vehicles and control units you own or are authorized to service. Before coding or programming, preserve the vehicle’s original configuration and follow appropriate Mercedes-Benz service procedures.
